They can be shaped according to specific requirements. The pores in these filter elements are crisscrossed, providing good resistance to both high and low temperatures, as well as excellent corrosion resistance, allowing them to be used in acidic and alkaline environments.
Diameter: Min 10mm, 35mm, 100mm; other size customized.
Lengtht: 500mm, 1000mm, 1200mm (special size available upon request);
Diameter of disc: 10mm, 3200mm (special dimensions can be customized);
Materials and operating temperatures: 304 (≤300°C), 316L (≤320°C), 904L≤500°C, Hastall; special materials customized according to requirements.
Filtering accuracy: 5μm to 1000μm (for liquids); 1μm to 80μm (for gases).
Connection types: 222, 220, 222, 226, M36, M20 standard interfaces flange connections, quick-connect interfaces.
Can be back washing for regeneration;
Uniform pore size,
good fluidity;
The filter medium has high strength, low pressure drop
Resistant to high temperatures
Chemical corrosion, with a long service life.
Easy processed and shaped using plasma welding.
Sand control screens for oil and gas industries,
filtration using polymer materials,
water supply and drainage treatment in nuclear power plants,
liquid filtration and separation,
gas filtration and separation,
oil filtration and separation,
Stainless Steel Wire Mesh Cartridges excel in applications requiring surface filtration with excellent mechanical strength and easy cleaning. Their smooth pore channels facilitate effective backwashing and regeneration, making them ideal for high-temperature
Pleated metal filter elements are vital in many industrial applications. They remove contaminants from liquids and gases effectively. However, many people do not understand how they function or why they are essential. Understanding the structure and operation of these filters can help in choosing the right one for your needs.
Filtration efficiency is crucial for various industrial applications, and users often face challenges with clogging, reduced flow rates, and high maintenance costs. The introduction of pleated filter elements, particularly those from MetalNet, offers a solution to these problems
Industrial filtration systems face numerous challenges, such as high operational costs, frequent maintenance, and environmental compliance concerns. Many manufacturers are gravitating towards advanced solutions like pleated filter elements, especially metal filters
