Diameter : Minimum 10mm, 35mm, 100mm; other size customized.
Length t: 500mm, 1000mm, 1200mm (special size available upon request);
Diameter of disc: 10mm, 3200mm (special dimensions can be customized);
Materials and operating temperatures: 304 (≤300°C), 316L (≤320°C), 321 (≤500°C), 904L≤500°C, Hastall; special materials customized according to requirements.
Filtering accuracy: 5μm to 1000μm (for liquids); 1μm to 80μm (for gases).
Connection types: 222, 220, 222, 226, 215, M36, M28, M24, M22, M20 standard interfaces, threaded interfaces, custom interfaces, rod connections, flange connections, quick-connect interfaces.
Can be back washing for regeneration;
Uniform pore size,
Good fluidity;
The filter medium has high strength, low pressure drop
Resistant to high temperatures
Chemical corrosion, with a long service life.
Easy processed and shaped using plasma welding.
Sand control screens for oil and gas industries,
filtration using polymer materials,
water supply and drainage treatment in nuclear power plants,
liquid filtration and separation,
gas filtration and separation,
oil filtration and separation,
Stainless Steel Wire Mesh Cartridges excel in applications requiring surface filtration with excellent mechanical strength and easy cleaning. Their smooth pore channels facilitate effective backwashing and regeneration, making them ideal for high-temperature
