Working pressure: ≤28.7 MPa;
Working temperature: ≤280°C;
Medium viscosity: ≤230 Pa·S;
Metal mesh filter elements: 20 mesh to 400 mesh;
metal woven filter elements: 3 μm to 100 μm;
Material: The filter media mainly stainless steel square-mesh sheets. SS304 ,316,316L .
Structure : Include , SS wire net / SS sintered fiber , inner support , out protection layer , both end cap or connection part .
Size : OD 10” , 20” OD 60 mm, OD 65 mm , Length size : 10”，20”...
Connection types: 222, 220, 222, 226, 215, M36, M28, M24, M22, M20 standard interfaces, threaded interfaces, flange connections, quick-connect interfaces.
Stainless Steel Wire Mesh Cartridges excel in applications requiring surface filtration with excellent mechanical strength and easy cleaning. Their smooth pore channels facilitate effective backwashing and regeneration, making them ideal for high-temperature
Pleated metal filter elements are vital in many industrial applications. They remove contaminants from liquids and gases effectively. However, many people do not understand how they function or why they are essential. Understanding the structure and operation of these filters can help in choosing the right one for your needs.
Filtration efficiency is crucial for various industrial applications, and users often face challenges with clogging, reduced flow rates, and high maintenance costs. The introduction of pleated filter elements, particularly those from MetalNet, offers a solution to these problems
Industrial filtration systems face numerous challenges, such as high operational costs, frequent maintenance, and environmental compliance concerns. Many manufacturers are gravitating towards advanced solutions like pleated filter elements, especially metal filters
